A production RAG pipeline, stage by stage — with cost and retrieval-quality numbers

The pipeline at a glance

             ┌────────────────────┐
             │  1. Raw documents  │
             └─────────┬──────────┘
                       ▼
             ┌────────────────────┐
             │  2. Chunking       │   semantic + size guard
             └─────────┬──────────┘
                       ▼
             ┌────────────────────┐
             │  3. Embeddings     │   batched, cached
             └─────────┬──────────┘
                       ▼
             ┌────────────────────┐         ┌────────────────────┐
             │  4. Vector store   │◀──────▶│  7. Semantic cache │
             └─────────┬──────────┘         └────────────────────┘
                       ▼                            ▲
             ┌────────────────────┐                 │
             │  5. Retrieval      │─────────────────┘
             └─────────┬──────────┘
                       ▼
             ┌────────────────────┐
             │  6. Reranking      │   cross-encoder, top-k → top-n
             └─────────┬──────────┘
                       ▼
             ┌────────────────────┐         ┌────────────────────┐
             │  7. Generation     │◀──────▶│  8. Eval (offline) │
             └─────────┬──────────┘         └────────────────────┘
                       ▼
                  Answer + sources

The remainder of this post takes each stage in order. For every stage we cover: the choice we ship by default, why, the code, and the marginal cost per 1M queries.

Stage 1 — Documents

Most production RAG content is heterogeneous: PDFs, HTML dumps, transcripts, Notion exports, support tickets. The ingestion step that pays off most is one we are too quick to skip — structural extraction. Strip the navigation, the boilerplate footer, the disclaimer repeated on every page. The signal-to-noise ratio of your corpus is the single thing that the rest of the pipeline cannot fix.

For PDFs we run Unstructured with the fast strategy for typical text-heavy docs and the hi_res (Detectron2) strategy for diagram-dense ones. For HTML we use Mozilla Readability wrapped in a thin Node service. The choice is rarely about quality at the extraction layer — it is about consistency. Pick one and run all of your content through it.

Stage 2 — Chunking

The chunk-size choice is the most discussed and most over-tuned decision in the pipeline. The honest answer from our four-product sample: recursive character splitting at 600-1000 tokens with 10-15% overlap covers 80% of use cases. The cases where it fails are where you knew it would fail: code (split on AST), tabular data (split on rows), legal prose (split on clauses or sections).

from langchain_text_splitters import RecursiveCharacterTextSplitter

splitter = RecursiveCharacterTextSplitter(
    chunk_size=800,
    chunk_overlap=100,
    length_function=len,           # characters; ~250 chars ≈ 60 tokens
    separators=["\n\n", "\n", ". ", " ", ""],
)

def chunk_document(doc: Document) -> list[Chunk]:
    pieces = splitter.split_text(doc.text)
    return [
        Chunk(
            text=p,
            metadata={
                "doc_id": doc.id,
                "title": doc.title,
                "section": nearest_heading_for_offset(doc, offset_of(p)),
                "page": page_for_offset(doc, offset_of(p)),
                "source_url": doc.source_url,
                "ingested_at": doc.ingested_at,
            },
        )
        for p in pieces
    ]

Two things to know. First, retrieval works on semantic similarity to the query, not on document hierarchy — so adding section headings to the chunk text itself (prefixed at the top of each chunk) measurably improves retrieval on multi-section documents. Second, chunks that are too small lose context; chunks that are too large dilute the relevance signal. Across our four products, the recall@5 curve peaks between 600 and 900 tokens; everything outside that window is a real, measurable regression.

Stage 3 — Embeddings

The embedding model is where you can save the most money for the least quality loss. The frontier-tier models (OpenAI text-embedding-3-large, Voyage voyage-3-large) are not always materially better for typical English prose than the smaller-tier options. The honest comparison:

The takeaway: text-embedding-3-small at $0.02 per million tokens is what we ship by default. The frontier tier (3-large) costs ~6.5× as much for a five percentage-point recall gain — rarely worth it unless the application is high-stakes (legal, medical). For budget-sensitive workloads, BGE self-hosted is competitive if you already run GPU infrastructure.

The cost-vs-model curve is the same one we map on the feature side in our companion AI feature token economics study. The pattern is consistent: the cheap model is good enough far more often than first instinct suggests.

Stage 4 — Vector store

The three we have shipped to production, in rough order of how often we pick them now:

• Postgres + pgvector — 0 ops overhead if you already run Postgres. Fast enough up to ~5M vectors with HNSW. Joins to your relational data are free. This is what we use for the majority of new builds.
• Pinecone / Weaviate / Qdrant Cloud — managed dedicated service. Faster at high cardinality, comes with namespace + metadata filtering UX. Worth it from ~10M vectors onward.
• LanceDB or DuckDB-VSS — in-process embedded option for batch / analytical RAG workloads. Trivially cheap, no network hop, ideal for the eval loop.

CREATE EXTENSION IF NOT EXISTS vector;

CREATE TABLE chunks (
  id          uuid          PRIMARY KEY DEFAULT gen_random_uuid(),
  doc_id      uuid          NOT NULL,
  text        text          NOT NULL,
  embedding   vector(1536)  NOT NULL,
  section     text,
  page        int,
  source_url  text,
  is_current  boolean       NOT NULL DEFAULT true,
  ingested_at timestamptz   NOT NULL DEFAULT now()
);

CREATE INDEX chunks_embedding_idx
  ON chunks USING hnsw (embedding vector_cosine_ops)
  WITH (m = 16, ef_construction = 64)
  WHERE is_current;

CREATE INDEX chunks_doc_id_idx ON chunks (doc_id) WHERE is_current;
CREATE INDEX chunks_source_url_idx ON chunks (source_url) WHERE is_current;

Stage 5 — Retrieval

The retrieval call itself is a thin wrapper around the vector store. The decisions here are k (how many chunks to fetch), the metadata filter, and whether to do hybrid retrieval (vector + keyword).

We retrieve k=20 by default and rely on the reranker (next stage) to narrow to the 4-6 that get into the prompt. Going wider on retrieval and tighter on reranking is consistently better than the reverse, because the cross-encoder used for reranking is far more discriminating than cosine similarity.

export async function retrieve(
  query: string,
  queryEmbedding: number[],
  tenantId: string,
  k = 20,
): Promise<RetrievedChunk[]> {
  const [vector, lexical] = await Promise.all([
    db.query(`
      SELECT id, text, doc_id, source_url,
             1 - (embedding <=> $1) AS score
      FROM chunks
      WHERE is_current AND tenant_id = $2
      ORDER BY embedding <=> $1
      LIMIT $3
    `, [queryEmbedding, tenantId, k]),
    db.query(`
      SELECT id, text, doc_id, source_url,
             ts_rank(to_tsvector('english', text), plainto_tsquery('english', $1)) AS score
      FROM chunks
      WHERE is_current AND tenant_id = $2
        AND to_tsvector('english', text) @@ plainto_tsquery('english', $1)
      ORDER BY score DESC
      LIMIT $3
    `, [query, tenantId, k]),
  ]);

  return reciprocalRankFusion(vector.rows, lexical.rows, k);
}

function reciprocalRankFusion(
  a: RetrievedChunk[],
  b: RetrievedChunk[],
  k: number,
  rrfK = 60,
): RetrievedChunk[] {
  const scores = new Map<string, { chunk: RetrievedChunk; score: number }>();
  for (const list of [a, b]) {
    list.forEach((chunk, rank) => {
      const score = 1 / (rrfK + rank);
      const existing = scores.get(chunk.id);
      if (existing) existing.score += score;
      else scores.set(chunk.id, { chunk, score });
    });
  }
  return [...scores.values()]
    .sort((x, y) => y.score - x.score)
    .slice(0, k)
    .map((entry) => entry.chunk);
}

The tenant filter on the SQL is non-negotiable on multi-tenant RAG — the most common RAG security failure we audit is a missing tenant scope on the vector query. The pattern is the same as the multi-tenant architecture study — enforce isolation in the database, not in the application. We ship this isolation pattern by default on every RAG build through our AI SaaS product development engagement.

Stage 6 — Reranking

The reranker takes the 20 retrieved candidates and scores them with a cross-encoder — a model trained to evaluate query / passage pairs directly, rather than comparing two independent embeddings. Cross-encoders are meaningfully better than bi-encoders for the final ranking step; the trade-off is they require a forward pass per candidate, so you cannot use them for the first retrieval.

The two we use: cohere-rerank-3.5 (API, $2 / 1k queries with up to 100 docs each) and BAAI/bge-reranker-large (self-hosted, free if you already have a GPU). Both move recall@4 up by 8-14 percentage points compared to no reranking, in our evaluation set.

import { CohereClient } from "cohere-ai";
const cohere = new CohereClient({ token: process.env.COHERE_API_KEY! });

export async function rerank(
  query: string,
  candidates: RetrievedChunk[],
  topN = 5,
): Promise<RetrievedChunk[]> {
  if (candidates.length === 0) return [];
  const res = await cohere.v2.rerank({
    model: "rerank-v3.5",
    query,
    documents: candidates.map((c) => c.text),
    topN,
  });
  return res.results.map((r) => candidates[r.index]);
}

Stage 7 — Generation

The prompt template that has held up best across our four products: explicit grounding instruction, an inline source list, an instruction to cite by source id, and a refusal clause for when the retrieved context doesn't support an answer.

export function buildMessages(
  question: string,
  passages: RetrievedChunk[],
): ChatMessage[] {
  const sources = passages
    .map((p, i) => `[${i + 1}] (${p.metadata.title})\n${p.text}`)
    .join("\n\n---\n\n");

  return [
    {
      role: "system",
      content: `You answer the user's question using only the SOURCES below. Cite each claim with the bracketed source number, e.g. [2]. If the sources do not contain the answer, reply exactly: "I don't have that in my sources." Do not invent facts.`,
    },
    {
      role: "user",
      content: `Question: ${question}\n\nSOURCES:\n${sources}`,
    },
  ];
}

Stage 8 — Semantic cache

The single biggest cost saver in a production RAG system is caching answers to semantically-similar questions. Two queries with different wording (“how do I reset my password” vs “forgot password reset”) should hit the same cached answer. The check is itself a vector similarity lookup, against a much smaller table of recent question embeddings + their generated answers.

CREATE TABLE rag_cache (
  id           uuid          PRIMARY KEY DEFAULT gen_random_uuid(),
  tenant_id   uuid          NOT NULL,
  question     text          NOT NULL,
  q_embedding  vector(1536)  NOT NULL,
  answer       text          NOT NULL,
  sources      jsonb         NOT NULL,
  hits         int           NOT NULL DEFAULT 0,
  created_at   timestamptz   NOT NULL DEFAULT now(),
  last_used_at timestamptz   NOT NULL DEFAULT now()
);

CREATE INDEX rag_cache_q_idx
  ON rag_cache USING hnsw (q_embedding vector_cosine_ops);

-- Tunable: how similar must a query be to hit cache?
-- 0.92 = strict (very few false positives, modest hit rate)
-- 0.88 = relaxed (more hits, occasional wrong cache match)

The threshold is the knob to tune. On our doc-Q&A client, 0.92 yields a 31% cache hit rate at <1% incorrect matches. Each hit saves the cost of the LLM call — the single most expensive line item by far.

Cost per 1M queries

Putting the numbers together, for a workload that retrieves k=20, reranks to top-5, and generates with Claude Haiku 4.5 (300 input tokens of context, 200 output tokens):

The semantic cache pays for itself within the first 100k queries on every production workload we have run it on. It is the single highest-leverage change for an already-shipped RAG product — and the one we add first when a team brings us a working but expensive RAG prototype through our AI app completion engagement.

Evaluation — the one part nobody wants to do

Build the eval set before you ship. 100-400 question / expected-answer pairs covering the surface area of the corpus. Run the full pipeline against them after every chunking, embedding, or prompt change — report recall@k for retrieval and a faithfulness score (LLM-as- judge) for generation. The version of this we run in CI for one of our doc-Q&A clients is ~140 questions and takes ~6 minutes per run. It has caught three regressions that would otherwise have shipped. Most of our RAG products ship as one feature inside a larger SaaS we built through the SaaS web-app development engagement — eval CI is wired in from day one rather than retrofitted.
